Wishbone Table Leg Router Templates (Clear Acrylic)

Wishbone Table Leg Router Templates - Clear Acrylic Woodworking Templates

Create clean, repeatable wishbone wooden table legs for custom furniture projects.

The Wishbone Table Leg Router Template is designed for woodworkers who want to make consistent wooden legs for dining tables, coffee tables, desks, and benches. The wishbone profile has a narrower top and a wider stance at the bottom, creating a strong furniture base with a more sculpted look than a simple straight-sided leg.

These templates are made from clear 1/4" acrylic, making it easier to position the template on your wood before cutting. Because the template is transparent, you can see the grain direction, colour variation, glue lines, and layout marks before committing to the final leg shape.

Each template comes in 8 interlocking pieces and uses a dovetail locking system to help with alignment during assembly and routing. Once assembled, the template can be reused to create matching wishbone legs for one project or repeat furniture builds.

What You Can Make With This Template

• Wishbone dining table legs
• Wishbone coffee table legs
• Wooden bench legs
• Custom desk legs
• Matching leg sets for repeat furniture builds
• Wooden furniture bases for solid wood, slab, and epoxy table projects

Why Use a Clear Acrylic Wishbone Table Leg Template?

A wishbone style table leg needs to feel balanced from top to bottom. The wider bottom stance gives the leg its shape, but both sides still need to match cleanly so the finished furniture piece looks intentional. A clear acrylic router template gives you a reliable pattern to follow and helps reduce layout time.

• Clear acrylic for better placement: See your wood grain, glue lines, colour, and layout marks through the template.
• Reusable for future builds: Use the same template again for dining table, coffee table, desk, and bench projects.
• Helps create matching legs: A consistent template makes it easier to keep each wishbone leg the same.
• Great for custom furniture work: Useful for one-off builds, client projects, and repeatable shop designs.
• Works well with hardwood blanks: A natural fit for solid wood boards or glued-up dimensional wood panels.

Recommended Products to Use With This Template

• Template Tape - Use this to secure the acrylic template to your wood before routing.
• Flush Trim Plunge Bit - Recommended for the first router pass to create the initial profile.
• UltraTrim Spiral Flush Trim Bit - Recommended for trimming the outside profile cleanly to match the template.
• Dimensional Wood - Choose hardwood boards or glued-up blanks for your table leg project.
• Universal Mounting Plates - Use these to attach your finished wooden legs to a dining table top, coffee table top, desk top, or bench top.
• Rubio Monocoat Hardwax Oil - A strong finish option for dining tables, desks, and higher-use furniture.
• Grand Finishing Hardwax Oil - A practical finish choice for coffee tables, benches, and other medium-use furniture projects.

How to Use This Wishbone Table Leg Template

1. Select your template size: Choose the dining table, coffee table, or bench version based on the furniture project you are building.
2. Prepare your wood blank: Use a solid board or glued-up hardwood panel that is large enough for the full wishbone leg profile.
3. Position the clear acrylic template: Place the template on your wood and adjust the layout so the grain direction, colour, and glue lines work well with the finished leg shape.
4. Secure the template: Apply Template Tape to hold the acrylic template firmly to the wood before routing.
5. Make the first router pass: Use the recommended Flush Trim Plunge Bit to establish the initial profile.
6. Remove excess material: Cut away the bulk of the waste with a band saw or jig saw, leaving a small amount of material outside the routed line.
7. Flush trim the final profile: Use a flush trim bit to clean up the remaining material so the wooden leg matches the acrylic template.
8. Sand and soften the edges: Sand the leg smooth and add an edge detail such as a roundover or bevel if desired.
9. Apply your finish: Finish the wooden legs with Rubio Monocoat or Grand Finishing Hardwax Oil, depending on the project and level of use.
10. Attach the legs: Use Universal Mounting Plates to secure the finished legs to your dining table top, coffee table top, desk top, or bench top.

Watch How to Use Acrylic Router Templates

New to router templates or looking for a cleaner workflow? Watch this video to see how acrylic woodworking templates are used in the shop.

Watch How to Attach Wooden Table Legs

Once your table legs are cut and finished, this video shows how to attach wooden legs to a table top using Universal Mounting Plates.

Template Details

• Template Style: Wishbone Table Leg Router Template
• Material: Clear acrylic
• Thickness: 1/4"
• Template Assembly: 8 interlocking pieces with dovetail locking system
• Use: Routing and shaping wooden dining table legs, coffee table legs, desk legs, and bench legs
• Reusable: Yes

Available Sizes

Dining Table Template

• 19" wide at the top
• 27.375" wide at the bottom
• 28" tall
• Template SKU: 08-016

Coffee Table Template

• 11" wide at the top
• 16.75" wide at the bottom
• 15" tall
• Template SKU: 08-017

Bench Template

• 8.5" wide at the top
• 13.625" wide at the bottom
• 17.5" tall
• Template SKU: 08-018

Helpful Router Template Guides

• Template Guides
• Table Leg Template Guide
• Router Template Guide
• What Router Bit Do I Need?
• Template Routing for Beginners

Frequently Asked Questions

Can I use this template to make full table legs?

Yes. This template is designed to help you create the full wishbone profile for wooden dining table legs, coffee table legs, desk legs, and bench legs.

Is this template reusable?

Yes. The template is made from clear acrylic and can be reused for multiple furniture projects when handled and stored properly.

Why is clear acrylic useful for this table leg template?

Clear acrylic makes it easier to position the wishbone shape on your wood blank before cutting. You can see the grain, colour, glue lines, and layout marks through the template.

What router bits should I use?

We recommend using the Flush Trim Plunge Bit for the first profile pass and the UltraTrim Spiral Flush Trim Bit for cleaning up the outside profile.

How do I attach the acrylic template to the wood?

Use Template Tape to hold the clear acrylic template securely to your wood blank while routing.

What type of wood should I use for this table leg project?

Solid hardwood or properly glued-up hardwood panels are a good fit for this type of project. Our Dimensional Wood collection is a natural place to start when choosing material for custom table legs.

How should I attach the finished legs?

We recommend using Universal Mounting Plates to attach the finished wooden legs to your dining table top, coffee table top, desk top, or bench top.

What finish should I use on the table legs?

For high-use furniture such as dining tables and desks, Rubio Monocoat Hardwax Oil is a great option. For medium-use furniture like coffee tables and benches, Grand Finishing Hardwax Oil is also a strong choice.

Build clean, consistent wooden table legs with a reusable Wishbone Table Leg Router Template. Whether you are making a dining table, coffee table, desk, or bench, this clear acrylic template helps simplify layout, routing, shaping, and repeatability.
